Piston depositor module (PDM)
The IPCO piston depositor module (PDM) system is a 1500 mm wide depositor that uses a D-motion to deliver chocolate or compound directly onto a moving belt. The speed and height of the depositor is software-controlled, ensuring that depositing is synchronized with the speed of the belt. This precision control, combined with the D-motion, means a variable deposit can be applied with no distortion, resulting in perfectly circular large products.
The PDM can be installed alongside existing equipment on IPCO CCM triple pass steel belt cooler lines. This enables three depositing systems – PDM, rotary depositor module (RDM) and chunk extruder – to be integrated on a single line for maximum production flexibility. It can also be installed as an upgrade to older CCM lines, or as a standalone system on new lines.
The unit offers a high degree of production flexibility as all key parts – piston blocks, pistons and valves – can be swapped when a mould pitch is changed. Similarly, all parts that come into contact with the product are easily dismantled for servicing. The depositor can be automatically removed from the production line onto a wheeled trolley unit for inspection, cleaning, servicing, and replacement/exchange of components.
How it works
The depositor travels longitudinally along the belt then completes the D-shape by returning to its starting position, using only rotational movements. This means there are no linear bearings to wear out, resulting in low maintenance requirements.
Benefits
High-productivity, small-footprint systems: Our triple pass process solutions enable high throughput rates from systems with a compact footprint
Rapid product changeover: Switch chip sizes in under 30 minutes by changing the depositor shell on our rotary depositor modules.
Three times the productivity: Our triple layer systems stack three production lines in a single unit just 40 m long
One production line, three high-quality products: We can combine chip, wafer, and chunk production in a single production line
Benefits
This low-maintenance, precision-controlled chocolate depositing system produces high quality, perfectly formed chocolate products.
1500 mm wide piston depositor
Suitable for large wafers, bar molding, one-shot products
Unique D-motion synchronized to belt speed
Twin chocolate containers with analogue level sensors
Easy access to parts for fast cleaning/switchover
No linear movement for less wear and tear
